Anping MamBa Screen Mesh MFG.,Co.Ltd
Home ProductsVibrating Screen Mesh

Manganese Steel 65mn Mining And Quarry Mesh For Mining Separating

I'm Online Chat Now

Manganese Steel 65mn Mining And Quarry Mesh For Mining Separating

Manganese Steel 65mn Mining And Quarry Mesh For Mining Separating
Manganese Steel 65mn Mining And Quarry Mesh For Mining Separating Manganese Steel 65mn Mining And Quarry Mesh For Mining Separating

Large Image :  Manganese Steel 65mn Mining And Quarry Mesh For Mining Separating

Product Details:
Place of Origin: China
Brand Name: Mam Ba
Certification: ISO9001,SGS
Model Number: Mining and quarry Mesh
Payment & Shipping Terms:
Minimum Order Quantity: 10 Square Meter
Price: $1500-$3000/Ton
Packaging Details: On Wooden or Iron Pallet
Delivery Time: Within7-15days
Payment Terms: L/C, T/T, D/A, D/P, Western Union, MoneyGram,OA
Supply Ability: 10000SM/Week
Detailed Product Description
Products Name: Mining And Quarry Mesh Tensile Stregth: 1500-1800Mpa
Weave Type: Plain Weave,Lock Type,Double Crimped,Slotted Opening,Intercrimp Aperture: 1mm-152.4mm
Wire Diameter: 0.5-19.04mm Wire Dia Tolerance: <3%
Aperture Tolerance: <3% Processed Wire: Annealing Process
Surface Treat: Rust Protection Feature: Wear Resistance
Screen Mesh Width: 100mm-2500mm Material: High Carbon Steel Alloys And 304 Stainless Steel
High Light:

manganese steel quarry mesh

,

mining separating quarry mesh

,

manganese steel quarry screen mesh

Mining and quarry Mesh For Mining Separating and Quarry
Mamba take pride in manufacturing our quarry screens and woven mesh screens to the highest of standards. We ensure that the highest quality high tensile and high carbon stainless steel wire is used in our screens.

Woven Wire Screen mesh is manufactured in both high tensile carbon steel and stainless steel from 1.6mm to 150mm, and in wire thickness ranging from 0.5mm to 19.05mm. Great care is taken from the start, from crimping the wire through to weaving, cutting to size and, finally, hooking the screens.

Our replacement mesh screens or woven screens are available in stainless steel mesh, self cleaning screens, piano wire screens, woven trommels, quarry screens and woven vibrating screen mesh. Mamba manufacture replacement screens to meet your machine specifications and requirements. Standard screen sizes which are available from stock.Woven Screens can be hooked to meet your requirements. Mamba woven trommels and woven screens are manufactured in square, slotted and elongated meshes.

Please Note: Overnight deliveries are possible on stock items if ordered early enough in the day. Special items not in stock will be promptly manufactured to meet your requirements.

CRIMP TYPES

FLAT TOP

All of the mesh knuckles are on the underside, allowing material to move more freely over the screen, while keeping plugging to a minimum.

DOUBLE CRIMP

Evenly crimped in warp and weft, providing a rigid construction. The wires are under-crimped and sprung together, thus giving a tight mesh. This is used mainky with lighter wires to ensure tension in a light screen.

LOCK CRIMP

A variation of the double crimp which ensures that the wires remain in their exact positions.

CORRUGATED CRIMP

Extra crimps in warp and weft with the wires seated in every third and fifth crimp. This creates a rigid mesh when making slotted mesh, even when the aperture is large in relation to the diameter of the wire.

Manganese Steel 65mn Mining And Quarry Mesh For Mining Separating 0


Mainly Material:highly abrasion-resistant spring steel wire or stainless spring steel wire.



Carbon Steel Wire Parameter:



No Grade Chemical Composition
C Si Mn
1 45 0.42-0.50 0.17-0.37 0.50-0.80
2 50 0.47-0.55
3 55 0.52-0.60
4 60 0.57-0.65
5 65 0.62-0.70
6 70 0.67-0.75
7 65Mn 0.62-0.70 0.90-1.20
8 72A 0.70-0.75 0.15-0.35 0.30-0.60



Stainless Steel Wire Paramter:



No Grade Chemical Composition
C Ni Mn Cr
1 304 ≤0.08 8.0-11.0 ≤2 18.0-20.0
2 321 ≤0.08 9.0-12.0 ≤2 17.0-19.0
3 316 ≤0.08 10.0-14.0 ≤2 16.0-18.5
4 2205 ≤0.03 4.5-6.5 2.5-3.5 21.0-24.0
5 2507 ≤0.03 6-8 ≤1.2 24-26



High Carbon Steel Alloys

High tensile crimping quality spring steel wire

The Tufflex™ Difference

The Strong and Durable Alternative Wire ... Tufflex wire is an alternative to high carbon and oil tempered wire. Finer grain structure and higher tensile strength offer greater consistency and flexibility throughout the screen,

offering both impact and abrasive resistance.

High Carbon

Abrasion-resistant, hard drawn, high carbon wire that can withstand repeated impact from heavy objects. Recommened for use when material to be screened is heavy and bulky, but moderately abrasive. High carbon wire has the least expensive initial cost.

Stainless Steel

Abrasion and corrosion-resistant, high tensile, hard drawn wire.

S304 Stainless

Standard alloy = 18% chrome / 8% nickel for excellent corrosion resistance.

S316 Stainless

Molybdenum is added to the basic 18% / 8% alloy for increased resistance to chemical corrosion.

S430 Stainless

Chromium alloy with no nickel for higher resistance to chemicals, atmospheric corrosion and oxidation. Handles temperatures up to 1,600 F.




Hook Types:
 Manganese Steel 65mn Mining And Quarry Mesh For Mining Separating 1


Selecting the right screening media



Mamba Screen is your total screening solutions company. That means no

matter what material you process, from sand to metallic ores, we have the right screen media and wear parts for your operation. Mamba’s experienced sales and engineering staff will help you select the product that best fits your applications.



Wire Cloth



1. More throughput and production

2.Readily available

3.Less upfront cost, compared to other options

4.More adaptable design options

5.Up to 10 foot wide widths and variable length options



Polyurethane



1.Extreme wear life, especially good for wet applications

2.Lower maintenance and fewer changeouts for more cost efficient production

3.Square or slotted openings

4.Modular or tension mats

5.Superior design optimizes open area



Rubber



1.Scalping applications and coarse dry screening

2.Crushed or natural, impact resistance and extended wear life in dry screening applications

3.High impact resistance

4.Low maintenance

5. Rubber vulcanized with steel plate recommended for heavy weight and high impact applications



Manganese Steel 65mn Mining And Quarry Mesh For Mining Separating 2



Manganese Steel 65mn Mining And Quarry Mesh For Mining Separating 3



Manganese Steel 65mn Mining And Quarry Mesh For Mining Separating 4
