Rubber Polyurethane Flop And Flip Flow Mats For Mining Recycling Metal Processing

I'm Online Chat Now

Rubber Polyurethane Flop And Flip Flow Mats For Mining Recycling Metal Processing

Rubber Polyurethane Flop And Flip Flow Mats For Mining Recycling Metal Processing
Rubber Polyurethane Flop And Flip Flow Mats For Mining Recycling Metal Processing Rubber Polyurethane Flop And Flip Flow Mats For Mining Recycling Metal Processing

Large Image :  Rubber Polyurethane Flop And Flip Flow Mats For Mining Recycling Metal Processing

Product Details:
Place of Origin: China
Brand Name: Rubber and polyurethane
Certification: ISO9001 SGS
Model Number: 006
Payment & Shipping Terms:
Minimum Order Quantity: 5-10pcs; Generally any qty is available, just cost is different.
Price: negotiable
Packaging Details: wooden box
Delivery Time: within 15days after confirmation
Payment Terms: L/C, D/A, D/P, T/T, Western Union, D/A, , Western Union
Supply Ability: 80pcs per day
Detailed Product Description
Products Name: Rubber And Polyurethane Flop And Flip Flow Mats For Mining, Recycling, Metal Processing Thickness: 3-10mm
Opening: 4-50mm Fastening Type: Bolt Or Clamp, Spaleck, Bivitec
Hole Type: Comb, Square, Oblong, Round,Rectangle Usage: Sand And Gravel,Metal Scraps,Industrial Minerals,Compost
Certificate: ISO 9001 And SGS Test Market: America, Africa, Australia, Some Of Europen Countries
Width: 200-600mm Length: 800-2900mm
Material: PU/TPU Hardness: Shore A 60-95
High Light:

Rubber Flip Flow Screens

,

Flop And Flip Flow Mats

,

Polyurethane Flow Mats

Rubber And Polyurethane Flop And Flip Flow Mats For Mining, Recycling, Metal Processing



POLY FLIP FLOW SCREEN Combining conventional circular vibration and traditional linear vibration Flip Flow screens are extremely efficient in difficult circumstances. The Flip Flow action minimises blinding and pegging when screening damp sticky materials. Mam Ba Flip Flow mats withstand deformation without loss of elasticity or dimensional accuracy. Our high energy elastic polyurethane system results in greater screening efficiency.



1. Customised Polyurethane formulation, Flexible and Durable



2. Designed to Fix into a wide range of Screen Decks



3. Ideal for dry, moist and humid environments



4. Various Apertures available in Square and Slotted



5. Various thickness (3-10mm), lengths (up to 2900mm) and widths



6. Hardness 80 – 90 Shore A

Flip-flow polyurethane screen mats for, Limestone, Dolomite, Flux, Basalt, Granite

Flip flow screen or flip flop screen is a type of PU screening media suited to efficiently screen dry, sticky, wet and other difficult materials. The large open area promotes the flow of materials while preventing blinding and clogging of the screen surface. Red Star can offer custom-made flip flow screen with different options of hardness, thickness, aperture opening size, shape and layout, no matter whether it is deployed in dry screening or wet screening applications.


Mamba has more than 10 different types of Polyurethane Flip Flow Screen for customers to choose,

Mamaba can also be customized to customer requirements of other sizes of Polyurethane Flip Flow Screen.



Polyurethane Flip Flow Screen Normal Specification



Normal Specification
Hardness 80-90A
Thickness 5-7mm
Resilience 45%-47%
Aperture Type Ellipse/Slot
Aperture Sizes 3×13mm - 50×50mm





Mam Ba High Performance Polyurethane Flip Flow Screen Media for Mining



Polyurethane Flip Flow Screen is mainly used for screening hard-to-screen materials, including sticky, fine and wet materials (such as highly sticky coal of high moisture content, and classification of medium & fine coke). The main advantages including high screening efficiency, long wearing life, wide application of particle size range, no pegging and no blinding. The flip flow screens are with high tensile strength, excellent wear performance, so as to achieve the designed service life of more than 4000 hours.




Polyurethane Flip Flow Screen Mode of Operation



The base frame is agitated by means of shaft and unbalance motor drive. The vibration is passed to the dynamic frame via thrust rubbers.Fixed screening mats between the dynamic and the base frame are clamped and fl exed by the two vibrating frames. The modular and compact construction of the Mam Ba Flip-Flow-Screen ensures a wide acceptance for many different applications. The easy assembly respectively changing of the screening mats, the extension to a multi-deck version and the dynamic stroke adaptation are further features. The vibrating cover can be opened without tools. This ensures a rapid and easy accessibility of the screening mats. The relative movement of both screening frames creates a “trampoline effect” for the screening mats. The advantages of this effect are:



1. High acceleration up to 50g in the screening mats



2. Loosening-up of the product

Polyurethane Flip Flow Screen Benefits


Non blinding screening mats – less contamination Compact and modular construction Single- or multi-deck execution Dynamic wear resistant screening mats allow an effi cient material flow – screwless mounted (fast changeover). The high acceleration on the screening mats ensures a self-cleaning effect. Infinite adjustment of the vibrating parameters to match changing product characteristics / qualities Low operating and maintenance costs





Application



Polyurethane Vibrating Screen is widely used for the classification of bulk material, such as coal, minerals, coke, beans, etc. So it can be used in the agriculture, chemical industry, minerals, quarry and smelting industries.


 Rubber Polyurethane Flop And Flip Flow Mats For Mining Recycling Metal Processing 0

Rubber Polyurethane Flop And Flip Flow Mats For Mining Recycling Metal Processing 1

Rubber Polyurethane Flop And Flip Flow Mats For Mining Recycling Metal Processing 2

Rubber Polyurethane Flop And Flip Flow Mats For Mining Recycling Metal Processing 3
