Heat Treatment Steel Wire Mesh For Sand And Gravel Industry

I'm Online Chat Now

Heat Treatment Steel Wire Mesh For Sand And Gravel Industry

Heat Treatment Steel Wire Mesh For Sand And Gravel Industry
Heat Treatment Steel Wire Mesh For Sand And Gravel Industry Heat Treatment Steel Wire Mesh For Sand And Gravel Industry

Large Image :  Heat Treatment Steel Wire Mesh For Sand And Gravel Industry

Product Details:
Place of Origin: HEBEI,CHINA
Brand Name: Mam Ba
Certification: SGS,ISO9001,ISO14001
Model Number: Steel Wire Mesh
Payment & Shipping Terms:
Minimum Order Quantity: 5-10 Pieces
Price: $1500-$3000/Ton
Packaging Details: Iron Pallet,plastic film inside , wooden case outside.
Delivery Time: 20-25 days
Payment Terms: L/C, D/P, T/T, D/A, O/A
Supply Ability: 1000-2000 Pieces per Week
Detailed Product Description
Products Name: Steel Wire Mesh Material: High Carbon Steel Wire, Patented Wire
Application: Mineral Processing, Sizing ,Quarry Wire Tolerance: <3%
Aperture Tolerance: <3% Processed Wire: Annealing Process,Patenting
Surface Treat: Rust Protection Screen Mesh Width: 500mm-2500mm
Length: Max 70meter Aperture Type: Slotted, Square, Rectganle
Hook Type: Side Tensioned, End Tensioned
High Light:

heat treatment steel wire mesh

,

gravel industry steel wire mesh

,

sand industry steel wire mesh

Passing Special Heat treatment Steel Wire Mesh for Sand and Gravel Industry

Mamba Screen Mesh MFG Company has a set of strict procedures to control the quality from materials to final products shipping. Our woven wire cloth has been widely accepted by clients from North America, Australia, Europe and Middle East for its high durability, precision and impact resistance. 90% of our products are used in international markets because they can be perfectly matched with various kinds of vibrating screens including international brands. For all of mining, aggregate, asphalt mixing and road construction industries, every cent saved from high quality production, fast parts changes and a longer part wear life will be eventually converted into hard profits and real cost reduction of companies. As the most important part of vibrating screens, a set of high-quality wire cloth with high accuracy, long wear life and high anti-impact is the foundation of production quality assurance in all industries above.



Mamba’s strict quality control system starts at the very beginning: selecting the right material. There are more than 500 steel works in China. We only chose 2 of them as our material suppliers. Except their stable quality (and good qualification we need), they must be able to customize steel wire rods in accordance with correct composition ratios we provide. Most importantly, they must be able to provide the test report of SGS, the international third party test organization for every batch of steel wire rods they produced.



Woven Wire Screen Mesh
Wire Diameter 0.50mm-19.05mm
Weaving Type Double Crimp,Lock Crimp,Flat Top,Inter Crimp
Aperture 1.00mm-152.00mm
Opening Type Square or Slot
Max width 2500.00mm
Products Type Flat Plates,Rolls, Folding Hook
Material High Carbon Steel Wire or Stainless Steel Wire.


Material:
highly abrasion-resistant spring steel wire or stainless spring steel wire.


No Grade Chemical Composition
C Si Mn
1 45 0.42-0.50 0.17-0.37 0.50-0.80
2 50 0.47-0.55
3 55 0.52-0.60
4 60 0.57-0.65
5 65 0.62-0.70
6 70 0.67-0.75
7 65Mn 0.62-0.70 0.90-1.20
8 72A 0.70-0.75 0.15-0.35 0.30-0.60




No Grade Chemical Composition
C Ni Mn Cr
1 304 ≤0.08 8.0-11.0 ≤2 18.0-20.0
2 321 ≤0.08 9.0-12.0 ≤2 17.0-19.0
3 316 ≤0.08 10.0-14.0 ≤2 16.0-18.5
4 2205 ≤0.03 4.5-6.5 2.5-3.5 21.0-24.0
5 2507 ≤0.03 6-8 ≤1.2 24-26


Weaving Type:

Heat Treatment Steel Wire Mesh For Sand And Gravel Industry 0

Hook Type:

Heat Treatment Steel Wire Mesh For Sand And Gravel Industry 1



Why Choose Mam Ba

More cost effective


Now, the material stage is ready. The wires will face one more test after they enter our factory. Our Quality Supervision Department will check its tensile strength, diameter and wire surface to decide if it can meet out company own standard which is actually higher than our National Standards..

Faster Delivery

30,00 tons production capacity per month of screen mesh, 2 million USD of screen mesh and 5 million USD raw materials-wire coils in stock, which make us to offer faster delivery time.One 20’GP Screen Mesh can be produced with in a day.

Stringent Quality Control

The company owns 18 patented products, all of them have been up to EU, GB and ASTM standards. The company has acquired certificates of ISO 14001 Environmental Management System, ISO 9001 Quality Management System and OHSAS 18001 Occupation Health Safety Management System.


Advanced Technologies

Our weaving technologies were introduced from Europe and USA. After more than 30 years Improving and Innovating,We can produce premium screen mesh,Polyurethane Screen and Parts, and offer special customized products.

HOW TO ORDER
Aggregate Screens and Industrial Wire Cloth In order to eliminate costly errors and delays, include the following information when ordering.
1. QUANTITY: Number of pieces or rolls.
2. WIDTH: Expressed in inches or fractions thereof.
3. LENGTH: Specify rolls or cut lengths in footage and/or inches.
4. OPENING OR MESH: A. Opening - Specify fractional or decimal space required. B. Mesh - Specify number of openings, counting from center of any wire to a point one inch distant.
5. WIRE SIZE: Expressed in decimals of an inch or Ind. Wire Gauge Number, or mm.
6. TYPE OF MATERIAL: Specify type of wire cloth: H/C, O/T or S/S.
7. PREFORMED SCREENS FOR MOUNTING IN VIBRATING OR SIZING MACHINES.
In addition to the above, the following information is required if the screen is preformed for mounting in machines:
A. Machine Type - Specify make of machine, serial number, model number and size.
B. Type Hooks - Specify type of hooked edges and also metal composi- tion in reinforced.
C. Finished Dimensions - Specify dimensions from outside of one hook to the outside of opposite hook. Also overall length.

Heat Treatment Steel Wire Mesh For Sand And Gravel Industry 2

Heat Treatment Steel Wire Mesh For Sand And Gravel Industry 3
