Flexi Mat Self Cleaning Screen Mesh Poly Strip Increased Wear Life

Product Details

Place of Origin: China

Brand Name: Mam Ba

Certification: ISO9001 SGS

Model Number: PU SCS

Payment & Shipping Terms

Minimum Order Quantity: 10 Square Meter

Price: negotiable

Packaging Details: On Wooden Carton or Pallet

Delivery Time: Within10-20days

Payment Terms: L/C, T/T, D/P, Western Union, MoneyGram

Supply Ability: 8000SM/Week

Get Best Price
Product Details
Highlight:

woven screen mesh

,

stainless steel woven wire mesh screen

Wire Material:
Stainless Steel Wire Or 65Mn Steel Wire
Wire Diameter:
0.50-6.00mm
Tensile Strength:
1700-1800Mpa
Aperture:
1-30mm
Strip Material:
High Quality Polyurethane
Feature:
High Screening Accuracy
Screen Mesh Width:
500-2500mm
Wire Tolerance:
<3%
Aperture Tolerance:
<3%
Products Name:
Poly Strip Self Cleaning Screen
Opening Type:
D,H,S Type
Wire Material:
Stainless Steel Wire Or 65Mn Steel Wire
Wire Diameter:
0.50-6.00mm
Tensile Strength:
1700-1800Mpa
Aperture:
1-30mm
Strip Material:
High Quality Polyurethane
Feature:
High Screening Accuracy
Screen Mesh Width:
500-2500mm
Wire Tolerance:
<3%
Aperture Tolerance:
<3%
Products Name:
Poly Strip Self Cleaning Screen
Opening Type:
D,H,S Type
Product Description

Mam Ba Wire Mesh MFG Company- Pu Strip Self Cleaning Screen





PU Strip Self Cleaning Screen Types of Weaves



Polyurethane screens have proven to be generally economical due to the long wear life and low maintenance requirements. Its wear life is enhanced by the polymers flexibility, which returns some of the impact energy imparted by the vibrating media. Noise is greatly reduced. Correctly applied Polyurethane screens can reduce or even eliminate plugging, pegging and blinding problems due to the tapered openings and resiliency of the material. Corrosion and rust are eliminated.



Anti-clogging wire screen, also known as Self Cleaning Screen, can drastically avoid the clogging and plugging of materials during screening. This type of screen is made of high tensile or stainless steel wires, with polyurethane bands that link crimped wires together.



Mam Ba Wire Mesh MFG Company’s polyurethane screen and anti-clogging screen have adopted the most advanced technology in the world. All equipment is imported from Europe.





PU Strip Self Cleaning Screen Material:


Main Material highly abrasion-resistant spring steel wire or stainless spring steel wire.



No Grade Chemical Composition
C Si Mn
1 45 0.42-0.50 0.17-0.37 0.50-0.80
2 50 0.47-0.55
3 55 0.52-0.60
4 60 0.57-0.65
5 65 0.62-0.70
6 70 0.67-0.75
7 65Mn 0.62-0.70 0.90-1.20
8 72A 0.70-0.75 0.15-0.35 0.30-0.60





No Grade Chemical Composition
C Ni Mn Cr
1 304 ≤0.08 8.0-11.0 ≤2 18.0-20.0
2 321 ≤0.08 9.0-12.0 ≤2 17.0-19.0
3 316 ≤0.08 10.0-14.0 ≤2 16.0-18.5
4 2205 ≤0.03 4.5-6.5 2.5-3.5 21.0-24.0
5 2507 ≤0.03 6-8 ≤1.2 24-26



Pu Strip Self Cleaning Screen Hook Types:



Our hook making adopts the electromagnetic coil heating process. All hooks are one-time forming. There are different type of hooks and edges available.

We can provide wire cloth with or without hooks and wire cloth rolls in different size according to client’s requests.



Pu Strip Self Cleaning Screen Characteristic



Our self cleaning screens are available in high tensile steel mesh or stainless steel. Also with or without polyurethane cross strips. Self cleaning screens are a non-blinding, high quality screening surface that provides accurate screening and sizing. Particularly where material is difficult, wet or sticky. In addition to having many advantages over other screen types, self cleaning mesh gives higher production rates. At the same time eliminating the problem of large unwanted flat material that contaminates the finished product.

THE BENEFITS OF SELF CLEANING SCREENS:

  • Anti-clogging
  • Increased wear life
  • Accurate sizing
  • Anti-pegging
  • Available to suit all types of mobile and static screens

With high quality, non-blinding screening is the perfect mesh. The combination of different size wire used in manufacture means that they vibrate at varying frequencies to produce a self-cleaning surface. Also, due to its flat surface (no knuckles) self cleaning screens can use a smaller wire diameter than woven wire for some applications. Therefore it has a greater opening area percentage and still lasts as long as normal square woven mesh.



PU Strip Self Clenaing Screen Shape Configurations:



Shape D is ideal for the medium and light materials. It is effectively controls the materials sizing through the equal openings. Shape D can do an excellent job no matter how strict the material sizing requirements.



Pu Strip Self Cleaning Screen The Shape S of self cleaning screen mesh is made of several horizontal and parallel crimped wires. It looks like the herringbone pattern, which can offer better sizing control than Shape S and Shape S by eliminating more flats and elongates



Shape V is specifically engineered and designed to reduce blinding and plugging conditions when the use of conventional square opening wire cloth is not acceptable. The Shape V screen accurately controls material sizing, both undersized, similar sized and oversized materials, while staying clean and remaining efficient



Application:
applies to vibrating screens for primary sieving of mine and aggregates, as well as asphalt mixer plant in road building.



Flexi Mat Self Cleaning Screen Mesh Poly Strip Increased Wear Life 0

Mam Ba Wire Mesh MFG Company’s wire cloth is the fruit of close cooperation with Canadian technology. All equipment in the factory are imported from Germany. Our company strictly follows International Standard, the Guide of Industrial Wire Screen and Woven Wire Cloth. Every process, including Crimping, Weaving, Hook Making, Edge Binding, has its own Work Sheet to cross-reference. Every process must be double-checked and approved by our Quality Supervision Department.
