OEM Quarry Screen Mesh #45 And 65mn High Carbon Steel Flexmat Self Cleaning

I'm Online Chat Now

OEM Quarry Screen Mesh #45 And 65mn High Carbon Steel Flexmat Self Cleaning

OEM Quarry Screen Mesh #45 And 65mn High Carbon Steel Flexmat Self Cleaning
OEM Quarry Screen Mesh #45 And 65mn High Carbon Steel Flexmat Self Cleaning OEM Quarry Screen Mesh #45 And 65mn High Carbon Steel Flexmat Self Cleaning OEM Quarry Screen Mesh #45 And 65mn High Carbon Steel Flexmat Self Cleaning

Large Image :  OEM Quarry Screen Mesh #45 And 65mn High Carbon Steel Flexmat Self Cleaning

Product Details:
Place of Origin: China
Brand Name: Mam Ba
Certification: ISO9001 SGS
Model Number: Flex Mat
Payment & Shipping Terms:
Minimum Order Quantity: 10 Square Meter
Price: 2000-10000USD/TON
Packaging Details: On Wooden Carton or Pallet
Delivery Time: Within10-15days
Payment Terms: L/C, T/T, D/P, Western Union, MoneyGram
Supply Ability: 8000SM/Week
Detailed Product Description
Wire Material: 65Mn High Carbon Steel Wire Or 45 Carbon Steel Wire Or SS 304 Wire Wire Diameter: 1.00-12.7mm
Tensile Strength: 1700-1800Mpa Aperture: 1-76.20mm
Strip Material: High Quality Polyurethane Feature: Anti-Clogging,Self Cleaning
Screen Mesh Width: 500-2500mm Wire Tolerance: <3%
Aperture Tolerance: <3% Porduction Type: Can Do OEM
Products Name: Self Cleaning Screen Mesh Aperture Type: V D H And S Type
MOQ: 5pcs Application: Qarry, Aggregate,Coal,Mining Industrial
High Light:

oem quarry screen mesh

,

quarry screen mesh self cleaning

,

flexmat self cleaning screen mesh

Mam Ba Wire Mesh MFG CO.,LTD



For all of mining, sand & aggregate, hot mix asphalt plants and road construction companies, every cent saved from high quality production, fast parts changes and a longer part wear life will be eventually converted into hard profits and real cost reduction of companies. As the most important part of vibrating screens, a set of high-quality wire cloth with high accuracy, long wear life and high anti -impact capability is the assurance of quality production in all industries above.



1.Material,looks the same but different



The best screens must have the right combination of all three critical factors- ductility, tensile strength and hardness. To achieve all 3 factors above, Red Star does not only focus on quality materials but also adopts special heat treatment process to improve overall performance of steel wires. After treatment, both internal structure and physical properties of steel wire has been significantly improved.



2.The Devil is in the details that is why we care



To make right screen media, Mam Ba, the biggest screen media manufacturer in China, has invested heavily in technology and equipment. We own 10 production lines and more than 600 crimping wheels. But more importantly, we own a capable and professional team of workers who always pay attention to details during the production.





3.Our ultimate goal: Zero Defect.



Building a successful team is not only about finding a group of people with the right mix of professional skills, but also about focusing on the goal, hardworking and leadership. To achieve our goal, namely making right screen media, Mam Ba has set up a set of strict working procedures to supervise the whole process.



Mainly Raw Material List:



Carbon Steel Wire Parameter:

No Grade Chemical Composition
C Si Mn
1 45 0.42-0.50 0.17-0.37 0.50-0.80
2 50 0.47-0.55
3 55 0.52-0.60
4 60 0.57-0.65
5 65 0.62-0.70
6 70 0.67-0.75
7 65Mn 0.62-0.70 0.90-1.20
8 72A 0.70-0.75 0.15-0.35 0.30-0.60



Stainless Steel Wire Parameter:

No Grade Chemical Composition
C Ni Mn Cr
1 304 ≤0.08 8.0-11.0 ≤2 18.0-20.0
2 321 ≤0.08 9.0-12.0 ≤2 17.0-19.0
3 316 ≤0.08 10.0-14.0 ≤2 16.0-18.5
4 2205 ≤0.03 4.5-6.5 2.5-3.5 21.0-24.0
5 2507 ≤0.03 6-8 ≤1.2 24-26



PU Strip Self Cleaning Screen Characteristics:


1. high performance production
2. More opening area
3. 30% more capacity than woven wire
4. Eliminates blinding and plugging
5. 3 times longer wear life time than woven wire
6.  Minimizes down time cleaning and unclogging
7. Maximizes throughput


Pu Strip Self Cleaning Screen Hook Types:

Our hook making adopts the electromagnetic coil heating process. All hooks are one-time forming. There are different type of hooks and edges available.
We can provide wire cloth with or without hooks and wire cloth rolls in different size according to client’s requests.

Pu Strip Self Cleaning Screen Characteristic

Our self cleaning screens are available in high tensile steel mesh or stainless steel. Also with or without polyurethane cross strips. Self cleaning screens are a non-blinding, high quality screening surface that provides accurate screening and sizing. Particularly where material is difficult, wet or sticky. In addition to having many advantages over other screen types, self cleaning mesh gives higher production rates. At the same time eliminating the problem of large unwanted flat material that contaminates the finished product.

THE BENEFITS OF SELF CLEANING SCREENS:

  • Anti-clogging
  • Increased wear life
  • Accurate sizing
  • Anti-pegging
  • Available to suit all types of mobile and static screens

With high quality, non-blinding screening is the perfect mesh. The combination of different size wire used in manufacture means that they vibrate at varying frequencies to produce a self-cleaning surface. Also, due to its flat surface (no knuckles) self cleaning screens can use a smaller wire diameter than woven wire for some applications. Therefore it has a greater opening area percentage and still lasts as long as normal square woven mesh.

PU Strip Self Clenaing Screen Shape Configurations:

Shape D is ideal for the medium and light materials. It is effectively controls the materials sizing through the equal openings. Shape D can do an excellent job no matter how strict the material sizing requirements.

Pu Strip Self Cleaning Screen The Shape S of self cleaning screen mesh is made of several horizontal and parallel crimped wires. It looks like the herringbone pattern, which can offer better sizing control than Shape S and Shape S by eliminating more flats and elongates


Shape V is specifically engineered and designed to reduce blinding and plugging conditions when the use of conventional square opening wire cloth is not acceptable. The Shape V screen accurately controls material sizing, both undersized, similar sized and oversized materials, while staying clean and remaining efficient.


Application:
applies to vibrating screens for primary sieving of mine and aggregates, as well as asphalt mixer plant in road building.

OEM Quarry Screen Mesh #45 And 65mn High Carbon Steel Flexmat Self Cleaning 0



OEM Quarry Screen Mesh #45 And 65mn High Carbon Steel Flexmat Self Cleaning 1

OEM Quarry Screen Mesh #45 And 65mn High Carbon Steel Flexmat Self Cleaning 2
