Product Details
Place of Origin: China
Brand Name: Mam Ba
Certification: ISO9001 SGS Testing
Model Number: Self Cleaning Screen
Payment & Shipping Terms
Minimum Order Quantity: 5 Square Meter
Price: 5000-13000USD/Ton
Packaging Details: Put into Wooden Carton or on Iron Pallet
Delivery Time: Within5-15days
Payment Terms: L/C, T/T, D/A, D/P, OA,Western Union, MoneyGram,CAD
Supply Ability: 7000SM/Week
Type: |
Self Cleaning Screen |
Material: |
Polyurethane And Optimus Steel Wire |
Wire Diameter: |
0.8-12.7mm |
Max Width: |
4000mm |
Max Length: |
2000mm |
Wire Tolerance: |
<3% |
Aperture Tolerance: |
<3% |
Application: |
Mineral Processing, Classification( Coarse-and Fine Screening), Scalping, And Aggregate Processing |
Product Name: |
Self Cleaning Screen Mesh |
Feature: |
Anti Clogging,Pegging And Blinding |
Aperture Type: |
D,H,L,S |
Aperture Sizes: |
1.25mm-76.2mm |
Type: |
Self Cleaning Screen |
Material: |
Polyurethane And Optimus Steel Wire |
Wire Diameter: |
0.8-12.7mm |
Max Width: |
4000mm |
Max Length: |
2000mm |
Wire Tolerance: |
<3% |
Aperture Tolerance: |
<3% |
Application: |
Mineral Processing, Classification( Coarse-and Fine Screening), Scalping, And Aggregate Processing |
Product Name: |
Self Cleaning Screen Mesh |
Feature: |
Anti Clogging,Pegging And Blinding |
Aperture Type: |
D,H,L,S |
Aperture Sizes: |
1.25mm-76.2mm |
Mam Ba Self Cleaning Screen
Mamba Screen Mesh MFG Company has a set of strict procedures to control the quality from materials to final products shipping. Our woven wire cloth has been widely accepted by clients from North America, Australia, Europe and Middle East for its high durability, precision and impact resistance. 90% of ourproducts are used in international markets because they can be perfectly matched with various kinds of vibrating screens including international brands. For all of mining, aggregate, asphalt mixing and road construction industries, every cent saved from high quality production, fast parts changes and a longer part wear life will be eventually converted into hard profits and real cost reduction of companies. As the most important part of vibrating screens, a set of high-quality wire cloth with high accuracy, long wear life and high anti-impact is the foundation of production quality assurance in all industries above.
Self Cleaning screens provide more effective use of screening surface area and greater production. Independent wires vibrate at high frequencies acting as a catalyst for quicker stratification of materials. Self Cleaning screens solves the toughest and most severe screening problems while maintaining materials in specification.
1.Engineered to decrease your cost per ton
2.Reduces blinding and pegging for fast effective screening
3.Increased screen life
4.Extensive range of openings
5.Newly innovative polyurethane strips
6.No modification required of crowned deck
| Aperture(mm) | Wire Diameter(mm) | |||
| 1.25 | 1.00 | |||
| 2.00 | 1.00 | 1.37 | ||
| 2.50 | 1.37 | 1.60 | 1.80 | |
| 2.75 | 1.37 | 1.60 | 1.80 | 2.00 |
| 3.15 | 1.37 | 1.60 | 1.80 | 2.00 |
| 3.50 | 1.37 | 1.60 | 1.80 | 2.00 |
| 4.00 | 1.60 | 1.80 | 2.00 | 2.50 |
| 4.50 | 1.60 | 1.80 | 2.00 | 2.50 |
| 5.00 | 1.80 | 2.00 | 2.50 | 3.15 |
| 6.00 | 1.80 | 2.00 | 2.50 | 3.15 |
| 6.30 | 2.00 | 2.50 | 2.76 | 3.15 |
| 7.10 | 2.00 | 2.50 | 2.76 | 3.15 |
| 8.00 | 2.00 | 2.50 | 2.76 | 3.15 |
| 9.00 | 2.50 | 2.76 | 3.15 | 3.50 |
| 9.50 | 2.50 | 2.76 | 3.15 | 4.00 |
| 10.00 | 4.00 | |||
| 11.10 | 2.50 | 2.76 | 3.15 | 4.00 |
| 12.70 | 3.15 | 4.00 | 4.50 | |
| 14.00 | 3.15 | 4.00 | 4.50 | 5.00 |
| 15.00 | 3.15 | 4.00 | 4.50 | 5.00 |
| 16.00 | 3.15 | 4.00 | 4.50 | 5.00 |
| 17.00 | 3.15 | 4.00 | 4.50 | 5.00 |
| 18.00 | 4.00 | 4.50 | 5.00 | |
| 19.00 | 4.00 | 4.50 | 5.00 | |
| 20.00 | 4.00 | 4.50 | 5.00 | |
| 22.00 | 4.00 | 4.50 | 5.00 | |
| 25.40 | 4.00 | 4.50 | 5.00 | |
| 28.00 | 4.00 | 4.50 | 5.00 | |
| 30.00 | 4.50 | 5.00 | 5.50 | 6.00 |
| 31.50 | 4.50 | 5.00 | 5.50 | 6.00 |
| 38.00 | 5.00 | 5.50 | 6.00 | 8.00 |
| 44.00 | 6.00 | 8.00 | 9.00 | |
| 50.00 | 8.00 | 9.00 | 11.10 | |
| 57.00 | 8.00 | 9.00 | 11.10 | 12.70 |
| 63.00 | 8.00 | 9.00 | 11.10 | 12.70 |
| 76.20 | 8.00 | 9.00 | 11.10 | 12.70 |
Custom specification are available on request
Mam ba self cleaning screens provide more effective use of available deck surface area and greater specification produced per unit time. Innovative polyurethane strips allow individual wires to vibrate independently from one another at variable frequencies. This popcorn effect prevents material build-up. Application: self cleaning screens are most efficient when screening and sizing of sand, gravel, limestone, coal, topsoil, crushed stone, blasted rock and compost.
